200mm Hole Dia Pancake Slip Ring Transferring 6A Per Wire With 100 Rpm Rotating Speed
Product Details
| Type | Pancake Slip Ring | Number Of Circuits | 2 |
|---|---|---|---|
| Current Rating | 6A Per Wire | Internal Diameter | 200mm |
| Feature | Compact Structure | Working Temperature | -20℃~ +60℃ |
| Voltage Rating | 240VAC/DC Or Higher | Torque | ≤0.12 G·m (for Reference ) |
| High Light | 200mm pan cake slip ring,high current slip ring,100 Rpm Pancake Slip Ring |
||
Product Description
200mm Hole Dia Pancake Slip Ring Transferring 6A Per Wire With 100 Rpm Rotating Speed
Quick detail
| Type | pancake slip ring |
| Number of circuits | 2 |
| Current rating | 6A per wire |
| Internal diameter | 200mm |
| Working speed | 100rpm |
Description
Fine brass rings are used for signals and can be plated with silver, gold or rhodium where low contact resistance and low noise levels are required. The best results are obtained when these precious metal surfaces are used in conjunction with silver-graphite brushes. These units are suitable for low speed only when fitted with brass rings.
A slip ring is a rotary coupling used to transfer electric current from a stationary unit to a rotating unit. This is accomplished by either:
1. Holding the center core stationary while the brushes and housing rotate around it.
2. Holding the brushes and housing stationary while the center core is allowed to rotate
Features
- 2 circuits model
- Low loss and low torque
- Industrial slip ring
- Smooth operation and reliable performance
- Low work speed and low electrical noise
- Compact structure & maintenance free
Alternatives
● Outside diameter
● Circuits
● Loading of each circuit
● Wire length
● Different signal compatible
● Working speed
| Specification | |
| Circuits | 2 circuits |
| Operating Speed | 0-100rpm |
| Working Temperature | -20℃~ +60℃ |
| Working Humidity | 60%RH or higher |
| Electrical: | |
| Voltage Rating | 240VAC/DC or higher |
| Current Rating | 6A per circuit |
| Dielectric Strength | ≥1000V@50Hz between each circuit |
| Insulation Resistance | 1000MΩ@ 500VDC |
| Electrical Noise | 1mΩ Min |
| Mechanical: | |
| Contact Material | Precious metal |
| Lead Wire Size | Tinning AWG17, |
| Lead Wire Length | Standard 300mm (11.811inch) |
| Housing Material | Aluminum alloy |
| Torque | ≤0.12 g·m (for reference ) |
| Protection | IP54 or higher |
