Single Channel High Frequency Coaxial Rotary Joint 6GHz 100rpm

Single-Channel High Frequency Rotary Joint with Small Size for Radar Antennas

The JINPAT LPCC-01B high frequency slip ring provides a reliable high frequency transmission solution between fixed and rotating platforms, ideal for applications including TV cameras, unmanned aerial vehicles, and radar systems.

This slip ring enables signal transmission from DC up to 6GHz and can be integrated with electrical slip rings for simultaneous power and high-speed data transmission. Designed for easy installation and maintenance with optimal lifespan.

• Connector type: SMA-K
• Frequency range: DC-6GHz
• Insertion Loss: within 0.3dB
• VSWR: within 1.4
• Working speed: 100RPM
• Lifespan: 1 million rotations

• Vehicle Turrets
• Radar Antennas
• Remotely Operated Vehicles
• Video Surveillance Systems
• Traffic Systems
