10 Wires Electrical Slip Ring RF Integrating Coaxial Rotary Joint with Wide Working Temperature

China 10 Wires Electrical Slip Ring RF Integrating Coaxial Rotary Joint with Wide Working Temperature supplier

Large Image :  10 Wires Electrical Slip Ring RF Integrating Coaxial Rotary Joint with Wide Working Temperature

Product Details:

Place of Origin: China
Brand Name: JINPAT
Certification: ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number: LPT000-0410-0602-HF01

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard/On Request
Delivery Time: 2 weeks ARO
Payment Terms: TT/CC/Paypal
Supply Ability: 500 pieces /Week
Contact Now
Detailed Product Description
Working Speed: 0~80rpm Working Temperature: -40~+70℃
Protection Level: IP54

10 Wires Electrical Slip Ring RF Integrating Coaxial Rotary Joint with Wide Working Temperature



Description

 The LPT000-0410-0602-HF01 slip ring is a through hole electrical part that is especially designed for vehicle-borne radar use. It can  not only transmit current, but also transfer HF signal. Being a 10 circuits device, it has a working voltage of 380VAC at a rotating speed of 80rpm.





Specifications



Circuits 4 circuits * 10A, 6 circuits *2A, 1 *HF
Working Voltage 380VAC
Dielectric Strength

Between circuits≥1000V@50Hz(current)

300V@50Hz(signal)

Insulation

500MΩ@500VDC (current)

100MΩ@300VDC (signal)

Electrical Noise ≤70mΩ (50rpm)
Working Speed 0~80 rpm
Contact Precious Metal
Housing Aluminum Alloy
Wire Size AWG17#/22#, Tin Plated Teflon
Wire Length

Rotor:500mm

Stator: Flying Lead Connection

Temperature -40°C~+70°C
Humidity ≤60%RH
IP IP54





Product Display



10 Wires Electrical Slip Ring RF Integrating Coaxial Rotary Joint with Wide Working Temperature



Company Glimpse

10 Wires Electrical Slip Ring RF Integrating Coaxial Rotary Joint with Wide Working Temperature





Company introduction



JINPAT has 20 years experience in SLIP RING manufacturing. Our factory covers an area of 7000 square meters with professional R&D team, advanced production equipment, and 300 skillful employees. JINPAT slip ring is one of the best-known brands in Europe and North America.


It has advanced technical equipment with high precision test instruments. Our manpower is so competent that we meet the needs of different customers with various specifications in durability and a reliable quality.
