Single Channel High Frequency Coaxial Rotary Joint 100rpm rotary electrical joint

Place of Origin China
Brand Name JINPAT
Certification ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number LPCC-01B
Minimum Order Quantity 1
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms TT/CC/Paypal
Supply Ability 500 pieces /Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Frequency Range DC To 6 GHz Rotating Speed , Max 100rpm
Nut Material Brass Body Material Stainless Steel
Type Rotary Electrical Joint VSWR Within 1.4
Lifespan 1 Million Insertion Loss Within 0.3dB
High Light

rotary swivel joint

,

coax rotary joint

,

100rpm rotary electrical joint

Product Description

Slip Ring of Single-Channel High Frequency Rotary Joint with Small Size for Radar Antennas



Description



JINPAT single-channel high frequency slip ring offers high frequency transmission solution between a fixed platform and a rotary platform, such as TV cameras, unmanned aerial vehicles and radar systems.



The slip ring allows signal transmission in the frequency range from DC up to 6GHz, and it can be integrated into the electrical slip ring to transmit power and high speed data. The high frequency slip ring is identified as ease of installation, ease of maintenance and optimal life.



Features



  • Connector type: SMA-K
  • Frequency range: DC-6GHz
  • Insertion Loss: within 0.3dB
  • VSWR: within 1.4
  • Working speed: 100RPM
  • Lifespan: 1 million



Main Application



  • Vehicle Turrets
  • Radar Antennas
  • Remotely Operated Vehicles
  • Video Surveillance Systems
  • Traffic Systems



Dimension



Single Channel High Frequency Coaxial Rotary Joint 100rpm rotary electrical joint 0





Company Introduction


JINPAT has 20 years experience in SLIP RING manufacturing. Our factory covers an area of 7000 square meters with professional R&D team, advanced production equipment and more than 300 skillful employees. JINPAT slip ring is one of the best-known brands in the Europe and North America. Our manpower is so competent that we meet the demands having varied specifications with ensured durable and reliable quality.



Single Channel High Frequency Coaxial Rotary Joint 100rpm rotary electrical joint 1



PS:Apart from providing connector or terminal processing for clients, we have our own CNC center so that we can provide one-stop service of supporting parts manufacture like housing or other mounting-related mechanical parts.



Single Channel High Frequency Coaxial Rotary Joint 100rpm rotary electrical joint 2



Frequently Asked Questions



1. What do we do?

We focus on developing, designing, manufacturing high quality sliprings, and offer various solutions for rotating systems.



2. How long have we been in the business?

Jinpat established slip rings business since 1996. We have thousands of customers accepted our products or services.



3. What is a slip ring?

A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.



4. How do I choose a slip ring?

Proper selection of a slip ring solution requires details about your application’s operating parameters including total circuits, voltage and amps per circuit, operating speed, and mounting type. A good place to start your search is with our standard slip rings. If you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started.



5. Do you offer custom slip rings?

Yes, if you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started. Our engineers will come up with perfect solution for your needs.
