HDMI IP40 60rpm Signal Slip Ring Solution Good Adaptability
Place of Origin | China |
---|---|
Brand Name | JINPAT |
Certification | ISO9001.ISO14000.CE.UL.FCC.RoHS |
Model Number | LPC-12T-02U3-HD02(JP34-048-01HW) |
Minimum Order Quantity | 1PCS |
Price | Negotiable |
Packaging Details | Standard/On Request |
Delivery Time | 2 weeks ARO |
Payment Terms | T/T, C/C, Paypal |
Supply Ability | 500 pieces/week |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xRotating Speed | 0~60rpm | Contact Material | Gold To Gold |
---|---|---|---|
Housing Material | Aluminum Alloy | ||
Highlight | 60rpm Signal Slip Ring,HDMI Signal Slip Ring,Good Adaptability Signal Slip Ring |
Innovations from tradition, slip rings from JINPAT Electronics have been further developed for use in aviation. Due to the different working conditions, the equipments used in different aviation environment have different requirements for vibration, explosion-proof, temperature and anti-corrosion. JINPAT fully lives up to these expectations.
LPC-12T-02U3-HD02 is a high definition signal slip ring developed by our company, which taking the lead of originality in its area with advanced design idea and manufacturing technology. It is perfectly applied to Video Surveillance field that transmits HD video signal and other signals in 360° continuous rotation. It is of high quality and reliability, certified by ISO9001:2008/ ISO14001:2015 / UL.
Features & Advantages
l Simultaneous transmission of HD video, together with USB, power, and common signal is supported
l Stable transmission of HDMI video signal, certified by stringent tests and acknowledged by customers
l Light and compact
l No interruption or data package loss in a very long-time operation
l Water tight and vibration resistant
l IP66 high protection level
l Long service life
Specifications
Electrical & Electronics
|
Mechanical | ||
Circuits | Total : 36 circuits ; 2 circuits*USB3.0/2 circuits video signal | Rotating Speed | 0~60rpm |
Rating Voltage | 0-5VAC/DC |
Contact Material
|
Gold To Gold |
Dielectric Strength | 100VAC@50Hz |
Housing Material
|
Aluminum Alloy |
Insulation Resistance | 10MΩ@100VDC (P) |
Wire Length | Stator: 200mm Rotor: 200mm |
Dynamic Resistance Fluctuation Value | 35MΩ | ||
Lead Wire Size | USB 3.0/Microphone lead | / | |
Environmental |
Others
|
||
Temperature | -20°C~+60°C |
Life span
|
Customizable |
Humidity |
≤60%RH
|
Note: "P" stands for power, "S" stands for signal | |
Protection grade |
IP40
|
Outline Drawing
