Capsule Slip Ring 56 Circuits 2A Electrical Rotary Joint

  • Capsule Slip Ring 56 Circuits 2A Electrical Rotary Joint
Place of Origin China
Brand Name JINPAT
Certification ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number LPC063-56A
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms TT/CC/Paypal
Supply Ability 5K units/week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Circuits 56 CKT Rotating Speed 0-300rpm
Industrial -20℃~+60℃ Humidity 60%RH Or Higher
Life Span Customizable Voltage 240V VC/DC
Highlight

DC 240V Capsule Slip Ring

,

240VDC Electrical Rotary Joint

,

300rpm Capsule Slip Ring
Product Description

DC 240V Capsule Slip Ring 56 Circuits 2A Electrical Rotary Joint



The LPM micro-capsule slip ring can integrate 30 or more circuits, and the optional outer diameter is 12.5mm~16mm. This series adopts advanced military surface treatment technology, featuring high precision, compactness and easy assembly. The gold-to-gold contact ensures low resistance and long service life. Representative models: LPM 04A / 06A / 12F / 18C / 24A / 30A, etc. It can integrate various signals: Ethernet, USB, RS, LVDS, CAN bus, FireWire, SDI and HDMI, etc. In addition, various non-standard slip rings can be customized.



Product parameter table



Electrical & Electronics Mechanical Enviromental
Circuits 56 CKT Rotating
Speed		 0-300rpm or higher Temperature Industrial: -20℃~+60℃
56×2A Military: -50℃~+80℃
Voltage 240V VC/DC Contact
Material		 Precious Metal Humidity 60%RH or higher
Housing
Material		 Aluminum Alloy Protection
Grade		 /
Dielectric Strength ≥500VAC@50Hz(P)
≥100VAC@50Hz(S)		 Torque ≤0.88 g.m
(for reference)		 Others
Insulation
Resistance		 ≥100MΩ@500VDC(P)
≥10MΩ@100VDC(S)		 Wire Type AWG30#
or others		 Life Span Customizable
Dynamic Resistance
Fluctuation Value		 ≤35mΩ Wire Length 250mm(optional)









JINPAT LPC063-56A compact size slip ring shares the same number of channels with LPC-56A. The differences between the two model are basically their sizes and some properties. LPC063-56A capsule slip ring is shorter than LPC-56A, the former is only 63mm. Since it has a relatively smaller size at large, the rated voltage of LPC063-56A is 110V while the LPC-56, 220V. Meanwhile the rated current is lowered with a smaller insulation strength, which is 1.5A for each channel. If you are looking for capsule slip ring with powerful transmission capacity, JINPAT is the right company you should turn to. Contact us for more slip ring models catalogue.
