LPCC-01C High Frequency Slip Ring IP40 80rpm 3million Revolutions

  • LPCC-01C High Frequency Slip Ring IP40 80rpm 3million Revolutions
Place of Origin China
Brand Name JINPAT
Certification ISO/CE/RoHS/UL
Model Number LPCC-01C
Minimum Order Quantity 10pcs
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms T/T, C/C, Paypal
Supply Ability 500 pieces /week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Interface Type N-F(75Ω) Frequency Range DC-12GHz
VSWR,Max 1.4 VSWR WOW 0.15
IP Protection Level IP40
Highlight

Robotics High frequency slip ring

,

80rpm High Frequency slip ring

,

12GHz High Frequency slip ring
Product Description

Typical Use

  1. Remotely operated vehicles

  2. Oceanographic winches

  3. Cable reels

  4. Towed arrays and dipping sonar

  5. Undersea telemetry

  6. Robotics

Options

  • Supply and installation of customer specific connectors and fibers

  • Customization of mounting configurations, housing materials and drive couplers

  • Fluid filling and pressure compensation for underwater use

  •

  •








Specifications(Without Cable)
Interface type N-F(75Ω) Axial Load On
Interface,Max		 ±10N
Frequency Range DC-12GHz Radial Load On
Interface,Max		 ±10N
VSWR,Max 1.4 Body Material Brass
VSWR WOW 0.15 Insulator Material PTFE
Insertion loss Max. 0.6dB Marking Laser marking
Insertion loss WOW. 0.15dB Weighe,approx 110g
Peak Power,Max, 1KW IP Protection Level IP40
Average Power,Max 100W@1GHz
15W@12GHz		 Operation Temperature -30~+75°C
Phase WOW,Max 3° Storage Temperature -30~+75°C
Rotating Speed,Max 80rpm Humidity(Operation) 95%
Life Time,Min 3million Revolutions Humidity(Storage) 95%
Staring Torque 10Ncm
@room temperature		 Continuous
Rotational Torque		 10Ncm
@room temperature
