Through Hole Rotary Slip Ring 36 Circuits 240 VAC/DC 300rpm For Cranes

Place of Origin China
Brand Name JINPAT
Certification ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number LPC-36T
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms TT/CC/Paypal
Supply Ability 500 pieces /Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Number Of Circuits 36 Hole Diameter 1.5~6mm
Contact Material Gold To Gold Capsule Length 68.5 Mm
Voltage 240 VAC/DC
High Light

rotary joint slip ring


miniature through bore slip ring

Product Description

6mm Through Hole Rotary Slip Ring Of 36 Circuits with 300rpm for Cranes




This unit can be used to mount the slip ring on a bracket or used for routing space for hydraulics.Multi-contacting can ensure contacting reliable with low wear.It is also called a rotary electrical interface, commutator, collector, swivel or an electrical rotary joint. It can improve electromechanical capability, simplify system design, eliminate possible damage while in the rotation.


The LPC-36T slip ring capsule can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary part to a rotating part. It is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connections.


Using a 90° V-groove ring design for each ring, the LPC-36T provides a smoother running, lower torque and lower electrical noise than competitive slip rings.





Operating Speed 0-200 rpm
Number of Circuits 36
Voltage 240 VAC/DC
Current Rating 2 amps per circuit
Temperature Range -20℃ to +60℃
Contact Material Gold to Gold
Lead Size 28# silver plated copper
Lead Lengths Standard 250 mm (9.843inch)
Hole Diameter 1.5~6mm
Dielectric Strength ≥500 VAC @50Hz, between each circuit
Insulation Resistance 100 MΩ @ 500 VDC
Electronic Noise 1mΩ Min



Outside Drawing

Through Hole Rotary Slip Ring 36 Circuits 240 VAC/DC 300rpm For Cranes 0


Application picture

Through Hole Rotary Slip Ring 36 Circuits 240 VAC/DC 300rpm For Cranes 1
