Diameter 38.1mm Rotary Joint Slip Ring 6 Circuit 15A 240VAC

  • Diameter 38.1mm Rotary Joint Slip Ring 6 Circuit 15A 240VAC
Place of Origin China
Brand Name JINPAT
Certification ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number LPT038-0615
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms TT/CC/Paypal
Supply Ability 100K units/week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Operating Speed 0-300rpm Circuits 6circuits
Working Temperature -20~ +60 Product Name Rotary Joint Slip Ring
Diameter 38.1mm Application Construction Machinery
Working Humidity 60%RH Or Higher Insulation Resistance 500MΩ/ 500VDC
Highlight

38.1mm Rotary Joint Slip Ring

,

Construction Machinery Rotary Joint Slip Ring

,

6 Circuit electrical rotary joint
Product Description

The LPT038-0615 aims at special application requirements of wind power generation system, JINPAT designed for wind power equipment manufacturers a variety of wind power slip ring, which is widely used in power generation 600KW - 5MW wind power system.

Standard product power circuits,Gigabit Ethernet signal or other signals can be custom.Please leave a message tell us your special needs!



Features

  •  Which has advanced production equipment and a variety of performance testing system.
  •  Good resistance for low temperature, wind resistance, corrosion resistance, impact resistance, anti
  •  vibration and other characteristics.
  •  The service life would be up to 20 years or more than hundred million rounds.
  •  Options include cable length, encoder type, and high current (300A) and so on.
  •  Please contact us to recommend you suitable product and customization design



Specification
Circuits 6circuits
Operating Speed 0-300rpm
Working Temperature -20~ +60
Working Humidity 60%RH or higher
Voltage Rating 240VAC/DC or higher
Current Rating 15A per circuit
Dielectric Strength ≥1000V@50Hz between each circuit
Insulation Resistance 500MΩ/ 500VDC
Via diameter 38.1mm
Contact Material Precious metal
Housing Material Aluminum alloy
Protection IP44 or higher



















































Product outline drawing

Diameter 38.1mm Rotary Joint Slip Ring 6 Circuit 15A 240VAC 0



Product Image

Diameter 38.1mm Rotary Joint Slip Ring 6 Circuit 15A 240VAC 1
