2 Circuits Pin Slip Ring with Precious Metal Contact for Packaging Machinery

Place of Origin China
Brand Name JINPAT
Certification ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number LPR-2H
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms TT/CC/Paypal
Supply Ability 500 pieces /Week
Product Details
Operating Speed 0-300 Rpm Number Of Circuits 2
Voltage 380 VAC/DC Current Rating 25A Per Circuit
Contact Material Precious Metal Housing Material Engineering Plastic
High Light

mini slip ring

,

small slip ring

Product Description

2 Circuits Pin Slip Ring with Precious Metal Contact for Packaging Machinery



Description



LPR-2H Series high Current slip ring provides routing space for hydraulics, pneumatics or a concentric shaft mount. The LPR-2H uses advanced fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. In addition, fiber brushes do not require lubrication and produce virtually no wear debris.



Outline drawing

2 Circuits Pin Slip Ring with Precious Metal Contact for Packaging Machinery 0

Features



◆ No mercury, environment-friendly design

◆ Pins connector, convenient for installation

◆ Speed up to 300 rpm continuous

◆ Steel bearings, machine shaft and housing for harsh environment

◆ Collar mount is standard; flange mount is optional

◆ Various lead exits are available

◆ Silver plated rings are standard. Gold plated optionally.

◆ Continuous 360°rotation of power or data signals transmission

◆ Sealed unit



Advantages



◆ Fiber brush technology provides operation free of maintenance (no lubrication required)

◆ Modular design meets special requirements through off-the-shelf manufacturing techniques

◆ Customized configurations for your application



Main Applications



◆ Packaging / Wrapping Machinery

◆ Semiconductor Handling Systems

◆ Industrial Machinery

◆ Rotary Index Tables

◆ Process Control Equipment

◆ Heavy Turrets or Cable Reels

◆  Display Machinery and Medical equipment

◆ Emergency Lighting, Robotics and Palletizing Machines,



Option



◆ Placement of custom circuitry directly onto the unit

◆ Custom mechanical integration features

◆ Addition of special components

◆ Inclusion of coax and miniature data bus cables



 Circuits 2
Voltage 380 VAC/DC
Rated Current  25A per circuit
Temperature Range -20℃ to +60℃
Contact  Precious metal
Connecting Way Silver plated pin
Housing  Engineering plastic
Lead Length Standard 250 mm (9.843inch)
Dielectric Strength ≥500 VAC @50Hz, between each circuit
Insulation Resistance 1000 MΩ @ 500 VDC
Electrical Noise 1mΩMin



Product picture

2 Circuits Pin Slip Ring with Precious Metal Contact for Packaging Machinery 1

Company Style



2 Circuits Pin Slip Ring with Precious Metal Contact for Packaging Machinery 2

Company introduction



JINPAT has 20 years experience in SLIP RING manufacturing. Our factory covers an area of 7000 square meters with professional R&D team, advanced production equipment, and 300 skillful employees. JINPAT slip ring is one of the best-known brands in Europe and North America.



It has advanced technical equipment with high precision test instruments. Our manpower is so competent that we meet the needs of different customers with various specifications in durability and a reliable quality.
