Capsule Slip Ring 12 Circuits LPM-12G

  • Capsule Slip Ring 12 Circuits LPM-12G
  • Capsule Slip Ring 12 Circuits LPM-12G
Place of Origin China
Brand Name JINPAT
Certification ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number LPM-12G
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms TT/CC/Paypal
Supply Ability 50K units/week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Number Of Circuits 12 Voltage 240 VAC/DC
Contact Material Gold To Gold Other Application Wind Power
One Application Total Station Two Application Motors And Generators
Lead Length Standard 250 Mm (9.843inch)
High Light

compact slip ring

,

mini slip ring
Product Description

Description



LPM-12G, whose contact part adopts rare metal and solid gold plating process, the slip ring has the feature of great wear resistance and antioxidant performance, which ensure the slip ring's long service life effectively.

LPM-12G compact capsule slip ring has a low torque design, with gold-on-gold contacts resulting in low electrical noise. These lead wires are flexible and color-coded, used to transfer analog and digital signals. It can be used at teams (CCTV), robotics, cable reels, medical equipment and packaging machines.



The slip rings are manufactured by utilizing premium grade metal-alloys using the edge-cutting technologies with the help of our deft team members. The offered slip rings are assembled in varied mechanical components to increase the rate of power transmission.





Specifications
Operating Speed 0-300 rpm
Number of Circuits 12
Voltage 240 VAC/DC
Current Rating 1 amps per circuit
Temperature Range -20℃ to +60℃
Contact Material Gold to Gold
Lead Size 30# silver plated copper
Lead Length Standard 250 mm (9.843inch)
Dielectric Strength ≥500 VAC @50Hz, between each circuit
Insulation Resistance 1000 MΩ @ 500 VDC
Electrical Noise 1mΩMin



Capsule Length =L
# of Circuits L (mm) Part No
12 20.00 LPM-12J

Outline Drawing

Capsule Slip Ring 12 Circuits LPM-12G 0



Application picture

Capsule Slip Ring 12 Circuits LPM-12G 1
